Amplificator de putere NAD C 298, stereo

NAD
Share

Ridicare gratuita din showroom

Cod produs: nad_C298

In stoc

8.399 lei / Bucata 11.999 lei

30 de zile perioada de retur

Garantie 24 luni

Transport gratuit pentru comenzi peste 100 RON in Romania

Livrare prin curier sau ridicare din showroom Bucuresti

Pentru plata în rate alegeți NETOPIA ca procesator de plăți.

6 Rate

Card Avantaj

6 Rate

Alpha Bank

6 Rate

6 Rate

Banca Transilvania

6 Rate

Garanti Bank

12 Rate

Raiffeisen Bank (in showroom)

Descriere

Purifi Eigentakt™ Amplifier Technology
Balanced Line Inputs
2 x 185W into 8 Ohms
2 x 340W into 4 Ohms
Stereo Dynamic Power 260/490/570W @ 8/4/2 Ohms
620W x 1 Rated Output into 8 Ohms Bridge Mode
Mono Dynamic Power 1000/1100W @ 8/4 Ohms
Single-Ended Line Inputs
Input Level Control
Line Output for Daisy Chaining
12V Trigger In/Out
Auto Turn-on with Selectable Threshold
IR In/Out
Ground Lug
Detachable AC Power Cord

Alte informatii

Link producator: click aici

Manual: descarca fisierul

Fisa de produs: descarca fisierul

Cauti un pachet PROMO personalizat?

Spune-ne de ce ai nevoie si revenim cu o oferta " de nerefuzat "

Specificatii tehnice Amplificator de putere NAD C 298, stereo

ANALOG AUDIO INPUT/LINE OUT
THD (20 Hz – 20 kHz): <0.0005 % at 2V out
Signal-to-Noise Ratio: >120 dB (IHF; 20 Hz – 20 kHz, ref. 2V out)
Channel separation: >110 dB (1 kHz)
>100 dB (10 kHz)
Input impedance (R and C):
Single-ended: 56 kohms + 280 pF
Balanced: 56 kohms +280 pF
Maximum input signal: >7.0 Vrms (ref. 0.1 % THD)
Output impedance: 390 ohms
Frequency response: ±0.1 dB (20 Hz – 20 kHz)
Maximum voltage output -IHF load: ≥>7.0 V (ref. 0.1 % THD)

ANALOG AUDIO INPUT/SPEAKER OUT
Rated output power into 8 Ohms and 4 ohms (Stereo mode, ref. 20 Hz-20 kHz at rated THD, both channels driven):
185 W at 8 ohms
340 W at 4 ohms
Rated output power into 8 Ohms (Bridge mode, ref. 20 Hz-20 kHz at rated THD, both channels driven): 620 W at 8 ohms
THD (20 Hz – 20 kHz): <0.005 % (1 W to 185 W, 8 ohms and 4 ohms)
Signal-to-Noise Ratio:
>98 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)
>120 dB (A-weighted, ref. 185 W out in 8 ohms)
Clipping power (Stereo mode, at 1 kHz 0.1 % THD): >200 W
Clipping power (Bridge mode, at 1 kHz 0.1 % THD): >690 W
IHF dynamic power (Stereo mode, at 1 kHz 1 % THD):
8 ohms: 260 W
4 ohms: 490 W
2 ohms: 570 W
IHF dynamic power (Bridge mode, at 1 kHz 1 % THD):
8 ohms: 1000 W
4 ohms: 1100 W
Peak output current: >25 A (in 1 ohm, 1 ms)
Damping factor: >800 (ref. 8 ohms 20 Hz – 6.5 kHz)
Frequency response:
±0.2 dB (20 Hz – 20 kHz)
-3 dB at 60 kHz
Channel separation:
>100 dB (1 kHz)
>80 dB (10 kHz)
Stereo Mode input sensitivity (for 185 W in 8 ohms): Fixed Gain mode: 1.43 V
Stereo Mode Gain: Fixed Gain mode: 28.6 dB
Line In – Balanced and Single-ended: Variable Gain mode: 8.5 dB – 28.5 dB
Bridge Mode Sensitivity: Fixed Gain mode: 3.78 V for 620 W in 8 ohms
Line In – Balanced and Single-ended: Variable Gain mode at maximum: 1.41 V for 620 W in 8 ohms
Bridge Mode Gain: Fixed Gain mode: 25.4 dB
Line In – Balanced and Single-ended: Variable Gain mode: 14.5 dB – 34.5 dB
Standby power: <0.5 W

DIMENSION AND WEIGHT
Gross dimensions (W x H x D): 435 x 120 x 390 mm (17 1/8 x 4 3/4 x 15 3/8 inches)
Net weight: 11.2 kg (24.7 lbs)
Shipping weight: 13.6 kg (30 lbs)

C298

Redefining the State of the Art with Purifi Technology

Amazing Flexibility

The C 298 may be a basic Power Amp, but we have carefully thought through all the use cases typically encountered to create a rich feature content. Selectable balanced inputs make the C 298 a natural for studio use or connection to High End Preamps and Processors. These inputs include a trim control useful for matching to other components. A line out allows further addition of power on the same channel for additional speakers or subwoofers. Auto-sense with selectable threshold is perfect for automating complex systems or hiding the amp out of sight in a cabinet.

Getting the Basics Right

It is surprising how many seemingly advanced products in the market today often miss many of the most basic requirements for satisfying performance. Low noise circuits, accurate channel balance, proper input and output impedance characteristics, high overload margins and stability with difficult speaker loads. NAD starts by getting these things precisely right and advances from there.
