TV System
TV System (Analog): B/G,D/K
Tuner Channel Coverage (Analog): 45.25MHz-863.25MHz(Depend on country selection)
TV System (Digital Terrestrial): DVB-T/T2
Tuner Channel Coverage (Digital Terrestrial): VHF/UHF(Depend on country selection)
TV System (Digital Cable): DVB-C
Tuner Channel Coverage (Digital Cable): VHF/UHF/cable(Depend on country selection)
TV System (Digital Sat): DVB-S/S2
Tuner Channel Coverage (Digital Sat): Intermediate Frequency 950-2150MHz
Number of Tuners (Terrestrial/Cable): 2(Digital)/1(Analog)
Number of Tuners (Sat): 2
Color System: PAL/SECAM/NTSC3.58(Video only)/NTSC4.43(Video only)
CI+: Yes
Color Space: sRGB/BT709,BT2020,AdobeRGB,DCI
Operating System: Android 10
On-board Storage (GB): 32GB
Display Features
X-Anti Reflection -
Display type: OLED
X-Wide Angle -
Backlight dimming type -
Display Specs
Screen Size (inch, measured diagonally)": 77"(76.8")
Screen Size for WEB(diagonal, cm, integer or 1st decimal): 195cm
Backlight type -
Display resolution (H x V, pixels): 3840 x 2160
Viewing Angle (Right/Left): 178(89/89) degree
Viewing Angle (Up/Down): 178(89/89) degree
Display Resolution: QFHD
Aspect Ratio: 16:9
Video Features
XR Backlight Master Drive -
Peak Luminance: XR OLED Contrast Pro
Features for PlayStation®5 Auto HDR Tone Mapping: Yes
Features for PlayStation®5 Auto Genre Picture Mode: Yes
LED Motion Mode -
Face Area Detection: Yes
Picture modes: Vivid, Standard, Cinema, IMAX Enhanced, Game, Graphics, Photo, Custom, Dolby Vision (Vivid/Bright/Dark), Netflix calibrated, BRAVIA CORE calibrated
Auto Wide: Yes
Wide Mode: Wide zoom/Normal/Full/Zoom/14:9,Normal/Full1/Full2 for PC
4:3 Default: Yes
Video Processing: XR 4K Upscalling
Motion enhancer: XR OLED Motion, Auto mode
Blinking Type: Frame Blinking
24p True Cinema: Yes
PhotoTV HD / BRAVIA 照片秀 for China: Yes
CineMotion/Film Mode/Cinema Drive: Yes
4K Processor: Cognitive Processor XR
HDR (High Dynamic Range) compatiblity: Yes(HDR10,HLG,Dolby Vision)
Panel Refresh Rate (Native Hertz): 100/120Hz
Audio Specs
Channel: 3.2ch
Audio Power Output: 20W + 10W + 10W + 10W + 10W
Speaker Position: Down Firing + Front
Bass/Treble/Balance: Balance
Speaker Type: Acoustic Surface Audio+
Speaker Configuration: Actuator x 3, Subwoofer x 2
DSEE/DSEE-HX -
Digital audio out (Optical) format: Two channel linear PCM: 48kHz 16bits, Dolby Audio, DTS(Pass through mode only)
Audio Features
Acoustic Center Sync: Yes (S-CENTER SPEAKER IN)
Ready for 360 Spatial Sound Personalizer: Y(with WLA-NS7)
Simultaneous Sound Output with TV Speaker -
Vertical Surround Engine: Vertical Surround Engine
Acoustic Auto Calibration: Room & User Position Compensation
Speaker Type-2 -
Clear Phase: Yes
Clear Audio+ -
S-Master: S-Master Digital Amplifier
Auto Surround: Yes
DTS audio format support: DTS Digital Surround
Sound modes: Standard, Dialog, Cinema, Music, Sports, Dolby Audio
Simulated surround sound: S-Force Front Surround
Dolby audio format support: Dolby Audio, Dolby Atmos
Voice Zoom: Voice Zoom 2
HDMI Audio Return Channel(ARC): Yes (eARC/ARC)
Advanced Auto Volume: Yes
Auto Mute (on no signal): Yes
FM Radio -
Audio Out -
Headphone/Speaker Link -
HDMI input Audio format: 5.1 channel linear PCM: 32/44.1/48/88.2/96/176.4/192kHz 16/20/24bits, Dolby Audio, Dolby Atmos, DTS
ARC output format: Two channel linear PCM: 48kHz 16bits, Dolby Audio, Dolby Atmos, DTS(Pass through mode only)
Network Features
Control Menu: Yes
ECO Dashboard: Yes
USB Tethering -
Apple AirPlay: Yes
Apple HomeKit: Yes
Home Network Feature: Home Network Client, Home Network Renderer
Wi-Fi Direct: Yes
Wi-Fi Certified: Yes
Screen mirroring(Miracast™): Yes (only for B2B purpose)
Video & TV SideView (iOS/Android): Yes
Related Info: Yes (UK, Ireland, Netherlands, Belgium, Luxembourg, France, Italy, Germany, Austria, Switzerland, Spain, Poland, Czech, Russia, Finland, Denmark, Sweden, Norway, Slovakia)
Wi-Fi Standard: a/b/g/n/ac
Wi-Fi Frequency: 2.4GHz/5GHz(for Wi-Fi Direct: 2.4GHz Only)
Photo Sharing Plus / Photo Share -
Internet Browser: Yes
Codec for Home Network: MPEG1:MPEG1/MPEG2PS:MPEG2/MPEG2TS(HDV,AVCHD):MPEG2,AVC/MP4(XAVC S):AVC,MPEG4,HEVC/AVI:Xvid,MotionJpeg/ASF(WMV):VC1/MOV:AVC,MPEG4,MotionJpeg/MKV:Xvid,AVC,MPEG4,VP8.HEVC/WEBM:VP8/3GPP:MPEG4,AVC/MP3/ASF(WMA)/LPCM/WAV/MP4AAC/FLAC/JPEG,WEBM:VP9/AC4/ogg/AAC/ARW(Screen nail only)
Wireless LAN: Integrated
Convenience Features
Multi-View -
Color Inversion -
TalkBack: Yes
Variable Refresh Rate (VRR): Yes (for HDMI3/4)
Auto Low Latency Mode (ALLM): Yes (for HDMI3/4)
Features specified in HDMI2.1: 4K120/eARC/VRR/ALLM
Built-in Mic switch: Yes(Center)
X-Protection PRO: Y (with Lightning, Surge, Humidity Protection)
Electronic Program Guide (EPG): Yes
USB HDD Recording: Yes(1Rec)(Except Italy)
Twin Picture -
Photo Frame Mode -
USB playback codecs: MPEG1:MPEG1/MPEG2PS:MPEG2/MPEG2TS(HDV,AVCHD):MPEG2,AVC/MP4(XAVC S):AVC,MPEG4,HEVC/AVI:Xvid,MotionJpeg/ASF(WMV):VC1/MOV:AVC,MPEG4,MotionJpeg/MKV:Xvid,AVC,MPEG4,VP8.HEVC/WEBM:VP8/3GPP:MPEG4,AVC/MP3/ASF(WMA)/LPCM/WAV/MP4AAC/FLAC/JPEG,WEBM:VP9/AC4/ogg/AAC/ARW(Screen nail only)
Built-in Mic: Yes
Screen Reader: Yes
Audio Description: Yes
Text Magnification: Yes
Accessibility Shortcut: Yes
Switch Access: Yes
Auto Picture Mode: Yes
Text Input Language: ARA / BUL / CAT / HRV / CES / DAN / DUT / ENG / EST / FIN / FRA / GER / GRK / HEB / IND / ITA / JPN / NOR / FAS / POL / POR / RON / RUS / SLK / SLV / SPA
Chromecast built-in: Yes
Voice Search: Yes*1
*1 Hands Free feature(Built-in Mic) availability depends on language and may need software update. Please check Sony support page for further information; https://www.sony.net/tv-hf-ww/
Application Store: Yes (Google Play Store)
BRAVIA Sync (including HDMI-CEC): Yes
Control for HDMI (HDMI CEC) -
Scene Select -
Parental Control: Yes
Channel Block (with password): Digital
Show/Hide Channels -
On Screen Clock: Yes
Sleep Timer: Yes
On/Off Timer: Yes
USB drive format support: Yes (Supported File System: FAT16/FAT32/exFAT/NTFS)
Display Language: AFR, AMH, ARA, ASM, AZE, BEL, BUL, BEN, BOS, CAT, CZE, DAN, DEU, GRE, ENG, SPA, EST, BAQ, PER, FIN, FRA, GLG, GUJ, HIN, HRV, HUN, IND, ISL, ITA, HEB, JPN, KAZ, KAN, KOR, KIR, LAO, LIT, LAV, MAC, MAL, MON, MAR, MAY, BUR, NOB, NEP, NLD, ORI, PAN, POL, POR, RUM, RUS, SOL, SLV, ALB, SRP, SWE, SWA, TAM, TEL, THA, TGL, TUR, UKR, URD, UZB, VIE, zh_CN, zh_HK, zh_TW, ZUL
Auto Shut-off -
Sensing Features
Sensor: Light
General Features
Auto Calibration with CalMAN: Yes
Closed Captions (Analog) -
Closed Captions (Digital): Subtitle
Demo Mode: Yes(e-POP only)
Emergency Warning System -
Hotel Mode Menu -
Broadcast Features
Teletext: Yes
Teletext number of pages: 1000 pages
Customizing Capability
RS-232C Control -
Design Features
Style -
Stand Position: 3way position (Standard position/Narrow position/Soundbar position)
Stand Color: Dark Silver
Bezel Design: Metal Flush Surface
Cable Management -
Frame color: Titanium Black
Stand Design: Aluminum Slim Wedged Stand
Illumination LED -
Stand Swivel -
Stand Tilt -
Inputs and Outputs
Media Connect -
HDMI Signal: 4096x2160p(24,50,60Hz),
3840x2160p(24,25,30,50,60,100,120Hz)*2, 1080p(24,30,50,60,100,120Hz),
1080i(50,60Hz),
720p(24,30,50,60Hz), 576p, 480p
*2 100Hz and 120Hz is supported by HDMI IN 3 and IN 4
HDCP: HDCP2.3(for HDMI1/2/3/4)
Bluetooth profile support: Version 4.2, HID/HOGP/SPP/A2DP/AVRCP
4K 60P High-Quality formats: HDMI IN1, IN2 ports for 4K(up to 18Gbps) signal, HDMI IN3, IN4 port for 4K(up to 48Gbps) signal
AC Power Input: C18 INLET (REAR)
RF (Terrestrial/Cable) Connection Input(s): 1(Side)
IF (Satellite) Input(s): 2(Side)
Composite Video Input(s): Hybrid w/S-Center Speaker Input x1(Side, Mini jack)
Component Video (Y/Pb/Pr) Input(s) -
HDMI inputs total: 4(4Side)
PC In (D-Sub) + Audio In (Stereo Mini) -
Analog Audio Input(s) (Total): 1(Side Analog Conversion)
Digital Audio Output(s): 1(Side)
Audio Output(s) -
Headphone Output(s) -
Subwoofer Output(s) -
USB ports: 2 (Side)
Ethernet inputs: 1(Side)
RS-232C Input(s) -
PCMCIA Slot(s): 1(Top)
HDMI PC Input Format: 640x480(31.5kHz,60Hz), 800x600(37.9kHz,60Hz), 1024x768(48.4kHz,60Hz), 1280x1024(64.0kHz,60Hz), 1152x864(67.5kHz,75Hz), 1600x900(55.9kHz,60Hz), 1680x1050(65.3kHz,60Hz), 1920x1080(67.5kHz,60Hz), 3840x2160p(30Hz), 3840x2160p(60Hz, 8bits)
Eco and Energy saving
Power Requirements (voltage): 220 V - 240 V AC
Power Requirements (frequency): 50 Hz
Power Consumption (Home Mode) for WEB -
Power Consumption (in Standby): 0.50 W
Power consumption(Networked Standby): 2.00W(Wi-Fi) / 2.00W(LAN) / 0.50W(CEC)
SORPLAS -
EEA SDR RANK: E
ECO Friendly: Yes
On Mode Power Consumption (Lot 5): 121 kWh/1000h
ErP Rank For EU -
Peak luminance ratio for EU -
Mercury content(mg): 0.0
Lead Content: Yes
Dynamic Backlight Control -
Power Saving Mode / Back Light Off Mode: Yes
Regulation and Standard Compliance
VESA® Hole Spacing Compatible: Yes
VESA® Hole Pitch(W x H): 30.0 x 30.0 cm
Measurements (Approx.)
Dimension of TV without Stand with Camera (W x H x D) -
TV with Stand (Front position) (W x H x D) *Measured incl. camera if bundled -
TV with Stand (Back position) (W x H x D) *Measured incl. camera if bundled -
Stand Width (Front position style) -
Stand Width (Back position style) -
Dimension of TV without Stand (W x H x D): Approx. 172.2 x 99.8 x 5.4 (2.79) cm
TV with Stand (Standard position) (W x H x D): Approx. 172.2 x 102.7 x 38.5 cm
TV with Stand (Narrow position) (W x H x D): Approx. 172.2 x 102.7 x 38.5 cm
TV with Stand (Soundbar position) (W x H x D): Approx. 172.2 x 106.9 x 38.5 cm
Dimension of TV with Floor Stand (W x H x D) -
Dimension of Package Carton (W x H x D): Approx. 185.8 x 113.0 x 18.8 cm
Stand width (Standard position): Approx. 138.5 cm
Stand width (Narrow position): Approx. 59.5 cm
Stand width (Soundbar position): Approx. 138.5 cm
Floor Stand Width -
AC Power Adapter size(W x H x D) -
DC Cable length of AC adaptor(mm) -
AC Cable Length: 2000mm
Weights (Approx.)
TV with Stand (Front position style/Back position style) -
Weight of TV without Stand: Approx. 34.8 kg
TV with Stand (Standard position): Approx. 36 kg
TV with Stand (Narrow position): Approx. 36 kg
TV with Stand (Soundbar position): Approx. 36 kg
Weight of TV with Floor Stand -
Weight of Package Carton(Gross): Approx. 47 kg
