AUDIO
Supported Audio File Formats: MP3, AAC, WMA, WMA-L, OGG, OPUS
Supported High-Quality Audio File Formats: FLAC, MQA, ALAC, WAV, AIFF, MPEG-4 SLS
DSD Support: DSD256
Supported Multi-Channel Audio Formats: Dolby® Digital, Dolby Atmos®, Dolby Digital Plus™, Dolby® TrueHD, *LPCM
Native Sampling Rates: up to 192 KHz
Bit Depth: 16-24
Audio Controls & EQ: BluOS Control App
Distortion: THD+N, 0.030%
Frequency Response: N/A
Amplification: Smart DSP Amplifier
Rated Power Output:
280W total system power
38W x 2 Tweeter. 38W x 2 Mid-Range, 65W x 2 Woofer
Speakers:
0.75" (21mm) Tweeter x 2; 1.5" (45mm) Mid-Range x 2;
4" (102mm) Woofer x 2; 4" (102mm) Passive Radiator x 2
Speaker Configuration: 2.1
SOFTWARE & INTEGRATIONS
Operating System: BluOS
App Controller Operating System: iOS, Android, Windows, macOS
Processor: ARM® Cortex™ -A53, Quad-Core, 1.8GHz per core
Supported Network File Sharing: Server Messsage Block (SMB) up to 200,000 files
Album Art Supported: JPG, PNG
Music Services & Internet Radio: 23+
3rd-Party Integrations: AirPlay 2, Spotify Connect (also support for Spotify Lossless), Tidal Connect, Roon Ready
Control System Integrations: Creston, Control4, RTI, Nice, URC, Lutron
Voice Control Integrations: Amazon Alexa Skills
CONNECTIONS
Power Supply: Universal 2-pin AC cord input (100-240AC)
Ethernet/LAN: Ethernet RJ45, Gigabit 1000Mbps
Wi-Fi Built In: 2x WiFi 5 (802.11ac), dual-band
Bluetooth Quality: Bluetooth 5.2 aptX Adaptive
Bluetooth Connectivity: Two-Way (transmit & receive)
IR Optical Built In: IR Sensor Built in - front panel with IR learning
Optical/Analog Input: Toslink Optical, RCA Analog
HDMI Input: HDMI eARC
USB In:
Type A (Fat32, NTFS Formatted) - External Storage Only
Local Server Mode
Headphone Output: Bluetooth
Subwoofer Output: RCA x 1; Wireless to PULSE SUB+
USER INTERFACE & CONTROL
Status Indicator: LED
Play/Pause Button: Touch LED
Volume Control Buttons: Touch LED
Previous/Next Track Buttons: In-App
Preset Buttons: Touch LED x2
Proximity Sensor: Yes
GENERAL
Max Power Consumption: N/A
Storage Environment: -10°C to 50°C, 20% to 80% relative humidity
Operating Environment: 0°C to 40°C
Product Dimensions:
Table
850 x 74 x 140 mm (W x H x D)
33.34 x 2.91 x 5.51 in (W x H x D
Wall Mounted
850 x 140 x 84.5 mm (W x H x D)
33.34 x 5.51 x 3.33 in (W x H x D)
Weight: 5.20 kg / 11.46 lbs
