SOUND
Recommended Room Size
15 - 60 m²
100 - 600 ft²
Speaker Configuration
12 speaker drivers
2 x 1" tweeter
4 x 2.5" full-range
2 x 3"" mid-range
1 x 5.25" mid-range + 1 x 1"" tweeter for custom made coaxial centre speaker
2 x 6.5" woofer custom made
Amplifier
12 power amplifiers
10 x 60 watts amplifiers for center channel, left/right/upfiring/side firing outputs
2 x 100 watts amplifiers for bass outputs
Total: 800 W
Frequency Range
28 Hz - 23,000 Hz
Maximum Sound Pressure Level @1m
112 dB SPL
Bass Capability
94 dB SPL
Advanced Sound Features
Integrated 7.1.4 Dolby Atmos decoding and custom-tuned post-processing with proprietary True Image up- / downmixing algorithm.
Advanced Bass management system
Adaptive Bass Linearization
Thermal protection
RoomSense
Automated speaker setup with external microphone:
Speaker level and distance
Speaker role
Speaker position compensation from 30 – 10.000Hz
Room resonance compensation from 30 – 200Hz
Sound format HDMI
Dolby Atmos supporting:
Dolby Digital TrueHD
Dolby Digital plus 7.1 (including DD5.1)
Dolby Atmos, Dolby MAT
PCM 7.1 multichannel
MPEG-2 AAC
MPEG-4 HE-AAC
Customizable Sound EQ
Presets available and fully customisable through the Bang & Olufsen App
DESIGN
Designer
Noto GmbH
Materials
Aluminium
Wood / Fabric
Fabric
Polymer
Dimensions
Soundbar table stand 19.7 h x 15.7 d x 122.2 w cm
Soundbar wall bracket, close position 18.9 h x 15.8 d x 122.2 w cm
Weight: 18kg
POWER
Power consumption
Typical 120 W
Power
100-240V 50/60Hz mains cable
CONNECTIVITY
Bluetooth Version
Bluetooth 5.1 (BLE and EDR)
Bluetooth Codecs
Android: SBC
iOS: SBC, AAC
WiFi
Dual-Band Wi-Fi 5 (2.4 & 5 GHz)
IEEE 802.11 b/g/a/n/ac
Streaming services
Apple AirPlay
Spotify Connect
Google Cast
TIDAL Connect
B&O Radio
Deezer
QPlay 2.0
Beolink Multiroom
Seamlessly connect multiple Bang & Olufsen speakers to expand your music experience.
Beolink Surround
Enjoy a true surround sound experience by connecting additional speakers to your setup through wired or wireless connections.
Wireless Connections
8 x Wireless Power Link/WiSA
4 x Digital Power Link (Wireless or wired, Mozart Platform-based Bang & Olufsen speakers)
Physical Connections
Soundbar inputs:
3 x HDMI input with CEC input
1 x HDMI eARC with passthrough 4K 120FPS / 8K 60FPS / 40Gbit
4 x 1Gbit Ethernet (One port assigned for LG OLED TV connection for integrated control via Beoremote One and Bang & Olufsen App)
1 x 3.5mm jack
1 x USB-C
Soundbar outputs:
8 x Power Link (RJ45)
4 x Digital Power Link (Wireless or wired, Mozart Platform-based Bang & Olufsen speakers)
Remote controls
Integrated system control, including LG OLED TV:
Bang & Olufsen App
Beoremote One BT
Beoremote Halo
TV remote (volume-mute-on-standby) control commands via HDMI ARC
On-Device Controls
Yes
Peripheral Unit Control
Integrated Peripheral Unit/Set-top Box Controller for two units, allowing you to control set-top boxes with the Bang & Olufsen remote control
