Multichannel Surround
Max. number of processing (preamp) channels: 2.1
Sound Enhancements
Discrete Power Amplifier: Yes
Pure Direct: Yes
Gold Plated RCA Terminals: Yes
Compressed Audio Restorer: Yes
Network
Media Server: Yes
HEOS Wireless Multi-Room Technology: Yes
Alexa / Google Voice Assistant / Apple HomePod: Yes / Yes / Yes
Lossy Formats: MP3 / WMA / AAC: Yes / Yes / Yes
Lossless Formats: FLAC / ALAC / WAV: Yes / Yes / Yes
Lossless Formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24: Yes / Yes / Yes
DSD Audio Streaming: Yes (2.8/5.6MHz)
FLAC HD 192/24: Yes
WAV 192/24: Yes
ALAC 192/24: Yes
Gapless playback: Yes (FLAC, WAV, ALAC ,DSD)
AirPlay Audio Streaming: Yes (AirPlay2)
Internet Radio: Yes (TuneIn)
Spotify Connect: Yes (connect)
Pandora: Yes
SiriusXM: Yes
Other Streaming Services: Amazon Music HD/ Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / Soundcloud / Mood Mix
Roon Tested: Yes
HEOS App Control: Yes
Compatible with Remote APP for Smart Phones: Denon AVR Remote
Compatible with Remote APP for Tablets: Android / iOS / Amazon Kindle
Ethernet Ports: Yes
Wi-Fi: Yes
Bluetooth: Yes
HDMI
HDMI Inputs: Back, Front: 6 / No
HDCP2.3 support: Yes
HDMI Outputs: Main, Zone: 1 / No
HDMI to HDMI Scaling: 1080P/4K to 8K
HDMI 2.1: 8K/60 Hz AB / 4K/120 Hz AB: Yes / Yes
8K/60Hz AB / 4K/120Hz AB Pass-Through In/Out: 3/1 (up to 40Gbps)
HDMI 2.0: 3D / 4K / CEC / ARC / InstaPrevue: Yes / Yes / Yes / Yes / No
HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR: Yes / Yes / No / Yes / Yes
ALLM (Auto Low Latency Mode) Pass-Through for Gaming: Yes
Variable Refresh Rate / Quick Flame Transport / Quick Media Switching: Yes / Yes / No
3D Signal Pass-Through: Yes
8K Signal Pass-Through, Scaling, GUI Overlay: Yes / Yes / Yes
4K Signal Pass-Through / Scaling / GUI Overlay: Yes / Yes / Yes
HDMI Pass-Though in Standby Mode: Yes
CEC: Yes
Audio Return Channel: ARC, eARC
Auto LipSync: Yes
Multi-room / CI
Multi-Room Zones: 2
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog: Yes (2ch) / Yes (2ch) / Yes / Yes
Zone Audio Output: Speaker / Pre-Out: No / Yes
IP Control / RS232 Control / Web Control / App Control: Yes / No /Yes / Yes
Remote In/Out: Yes / No
HDMI Diagnostics: Yes
Others
Front Display: 1 Line FLD
Graphic User Interface - GUI: HD GUI
GUI Languages: 3
Setup Assistent: Yes
Quick Select Plus, Quick Select: Yes / No
Firmware Update by Network / USB: Yes / Yes
ECO Mode: Yes
Auto Power Off: Yes
Sleep Timer: Yes
Inputs Outputs
VIDEO
HDMI In/Out: 6 / 1
AUDIO
Analog In, Out: 2 / No
Phono (MM) In: Yes
Digital in: Optical/Coaxial: 2 / 1
Multi-Room Out: Analog/Digital: 1 / No
Multichannel Pre-out: Yes (2.2)
Subwoofer Out: 2
OTHER
Speaker Terminal: Gold-Plated Screw / Regular Screw: Yes / No
Number of Speaker Terminals: 4
Speaker A / B: Yes
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB: No / No / No / No / Yes
USB Audio / Made for iPod / Made for iPhone: Yes / No / No
USB Power Supply on Rear Panel: Yes
AM/FM Tuner: Yes
Specifications
Number of Power Amps: 2
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive): 100 W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive): 120 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive): 175 W
General
System Remote Control: RC-1259
Power Consumption in W: 220W
Power Consumption No-Sound (ECO On / Off) in W: 23W/32W
Standby Consumption in W: 0.1
CEC Standby Consumption in W: 0.5
Network Standby Consumption in W: Less than 2.0
Maximum Dimensions
Antenna:Horizontal:(W x D x H) in mm: 17.1× 13.3 × 6
Antenna:Vertical :(W x D x H) in mm: 17.1 x 13.3 x 8.5
Weight in LBS: 18.3
Weight in LBS (Packaging): 23.1
Power Supply: AC 120 V, 60 Hz
Speaker Impedance: 4–16Ω/ohms
Pre-Amplifier Section
Input Sensitivity: 200 mV
Frequency Response: 10 Hz–100 kHz — +1, –3dB (Direct mode)
S/N Ratio: 98dB (IHF-A weighted, Direct mode)
FM section
Tuning Frequency Range: 87.5–107.9 MHz
AM section
Tuning Frequency Range: 520 kHz–1710 kHz
