Produsul a fost verificat de un specialist Audio Monkey, funcționează perfect, fără zgârieturi și beneficiază de garanție integrală asemenea unui produs nou.
Access to Spotify®, TIDAL, Deezer, TuneIn, and Pandora® are built into the system. Use dedicated apps (where available) or the free Onkyo Control App for Apple and Android devices to find and play music.
When playing any Dolby® format, engaging Dolby Atmos Height Virtualizer enables a more immersive listening experience, creating a virtual surround and height effect from traditional speaker layouts without employing additional surround or height speakers.
This receiver can join your existing Sonos Home Sound System, or be the start of a new one, just by pairing it with a Sonos Port.* This Works With Sonos Certified AVR offers a best-in-class tie-in to the Sonos ecosystem, waking, changing inputs, and playing at the volume you want using the Sonos Volume-Pass Through feature from the Sonos app*.
DTS Play-Fi allows you to enjoy high-quality music from connected online services, networked media servers, and your device library over Wi-Fi® to any number of compatible products using the Onkyo Music Control App for iPad, iPhone, and Android smartphones/tablets. DTS Play-Fi can synchronize the music in every room. Each member of your family can use their own device to listen to their music in a room or group of rooms. DTS Play-Fi lets you structure a comprehensive multi-room ecosystem that satisfies virtually any need.
AccuEQ streamlines the initial setup of your home theater system and ensures your receiver and speakers are properly calibrated for the best performance in your listening space. AccuEQ calculates speaker distance from the listening position, adjusts speaker sound pressure level, and sets the speaker crossover. The latter selects the correct point to roll off low-frequency sound to the subwoofer. The result is clear and balanced full-spectrum surround sound.
Refined over 70 years to deliver emotion in high fidelity, DAA features a custom High-Current Low-Noise Power Transformer, customized capacitors, and discrete amp output stages. Unique topology prevents phase-shift while high current improves speaker control for true dynamic speed. Driving 4-ohm loads through all channels, DAA has power to move.
Dolby Atmos® and DTS:X® formats allow engineers to map sound anywhere in 3D space, effects moving from speaker to speaker all around the room and wrapping your audience in the latest films and games. You can also enjoy your 3D speaker layout with classic titles. Dolby Surround® and DTS® Neural:X find overhead cues in legacy soundtracks and upmix for awesome spatial realism.
Features defined in HDMI® 2.1 specification enable 8K/60p video passthrough to your compatible display. As well as HDR10 and HLG, HDR10+ and Dolby Vision™ formats optimize brightness, contrast, and color scene-by-scene or frame-byframe.
All HDMI terminals support HDCP 2.3, while eARC on
Main Out passes encoded multichannel audio (including Dolby Atmos® or DTS:X®) from your compatible TV’s tuner, video streaming apps, or connected media players to the AVR for amplification. QMS (Quick Media Switching)
for movies and video eliminates the delay that can result in a blank screen before content is displayed.
Stream music from your smartphone, laptop, or PC to the receiver via Chromecast built-in and control playback from Chromecast-enabled apps you know and love from your iPhone, iPad, Android™ phone or tablet, Mac or Windows® PC, or Chromebook™. Cue, play, and control audio just by using your voice.
SMART AV Receiver shares audio around your home. It includes Amazon Music HD*, Spotify®, TIDAL, Deezer, and TuneIn, and works with Hey Google or Alexa. Share entertainment via Works with Sonos, AirPlay 2, DTS Play-Fi®, and Chromecast built-in.
* Amazon Music HD is supported via DTS Play-Fi.
Expand your Sonos Home Sound System by pairing this AVR to a Sonos Connect or Port*. The receiver ties into the Sonos ecosystem, waking, changing inputs, and playing at the desired volume on command from the Sonos app*.
* Sonos Connect and Port sold separately. The Sonos app is available free for iPhone and iPad from the App Store, and for Android™ phones and tablets on
Google Play Store.
Stream music from your smartphone, laptop, or PC to the receiver via Chromecast built-in and control playback from Chromecast-enabled apps you know and love from your iPhone, iPad, Android™ phone or tablet, Mac or Windows® PC, or Chromebook™. Cue, play, and control audio
just by using your voice.
Alexa lets you use your voice to control the A/V receiver by speaking commands through an Alexa built-in device. Whether you want to listen to music, radio stations, or podcasts, all you have to do is ask. It also supports multi-room music* played on multiple devices.
* Multi-room music may require a firmware update.
Dolby Atmos and DTS:X translate 3D soundtracks from the studio mixing desk to your living room. Sounds are no longer tied to specific channels, and are free to move around and above your audience, placing them at the heart of the action.
Dolby Atmos Height Virtualizer and DTS Virtual:X™ are sound virtualization solutions that deliver 3D sound through any listener-level speaker layout. The technologies can work independently or in conjunction with Dolby Surround® or DTS® Neural:X upmixers to create an immersive 3D sound-field with any audio signal (excluding Dolby Atmos, DTS:X, and DTS® Express).
A powerful quad-core SoC (System on a Chip) performs multiple processing tasks at once. It evolves network functions and supports the 802.11ac (2x2 MIMO) standard for stable multi-room audio streaming.
* Note: some countries or regions have regulations that affect wireless signal
strength and the use of Wi-Fi channels.
Vocal Enhancer solves the problem of inaudible dialog in movies and TV programs by using DSP algorithms to elevate vocal frequencies in the soundtrack. The effect level can be raised or lowered using keys on the remote control.
AccuEQ detects speaker size, crossover frequency, and distance from the listening position and sets sound-pressure levels appropriate to their location. It selects the ideal crossover for the subwoofers and applies EQ to all speakers including the subs. AccuReflex optimizes 3D sound through Dolby Atmos-enabled speakers by resolving phase-shift arising from differences in directional and non-directional sound-paths. The result is a clear and cohesive sound-field.
A powerful quad-core SoC (System on a Chip) performs multiple processing tasks at once. It evolves network functions and supports the 802.11ac (2x2 MIMO) standard for stable multi-room audio streaming.
* Note: some countries or regions have regulations that affect wireless signal
strength and the use of Wi-Fi channels.
Zone B pre-/line-out shares MAIN Zone audio to an audio system with an RCA line input. Enjoy what’s playing in the MAIN Zone on a hi-fi (or active speaker) system in a nearby space, or connect a compatible wireless headphone dock to enjoy entertainment at any time of day in privacy.
Multi-function speaker terminals can play any amplified audio in MAIN and Zone B at the same time. Alternatively, assign them to bi-amp compatible front speakers or expand a 5.2-ch layout with Surround Back speakers (7.2-ch) or Height speakers (5.2.2-ch).
PRODUCT HIGHLIGHTS
- 5.2.2-ch Dolby Atmos® and DTS:X® playback
- Dolby Atmos Height Virtualizer and DTS Virtual:X™ 3D sound virtualization technologies
- SMART AV Receiver™ Works with Sonos*1, Chromecast built-in™, AirPlay 2, and DTS Play-Fi®; includes Spotify®, Amazon Music HD*2, TIDAL, Deezer, and TuneIn streaming services*3
- Works with Ok Google or Alexa*4
- Stream over 5 GHz/2.4 GHz dual-band WiFi® supporting the 802.11ac standard*5
- HDMI® supports 8K/30p ( 4:2:0 / 12-bit ), 4K/120p ( 4:2:0/ 12-bit ), HDR10+, Dolby Vision and BT.2020 color; VRR ( Variable Refresh Rate ), ALLM ( Auto Low Latency Mode ),and QFT ( Quick Frame Transport ); eARC ( Main Out ), and HDCP 2.3
- HDMI Sub Out for media transmission to a projector, gaming monitor, or TV
- Send or receive audio via Bluetooth® wireless technology ( RX mode: SBC/AAC, TX mode: SBC/Qualcomm® aptX™/ aptX HD )
- Zone B pre-/line-out plays MAIN Zone audio to a compatible headphone dock
- Vocal Enhancer, media info and playback status display, and one-touch volume memory-preset functions
- AccuEQ with AccuRefl ex™ and subwoofer EQ
AMPLIFIER FEATURES
- 150 W/Ch ( 6 Ω, 1 kHz, 10% TH D, 1 channel d riven ), 135 W/Ch ( 6 Ω, 1 kHz, 1% THD, 1 channel driven, IEC )
- Discrete 2-stage power amplifi er circuitry
- Custom High-Current Low-Noise Power Transformer
- Isolated network module reduces high-frequency signal interference on audio circuitry
- High current capability drives 4-ohm loads through 7 channels
- Precision 192 kHz/24-bit D/A conversion for Hi-Res Audio
- PLL ( Phase Locked Loop ) anti-jitter technology for SPDIF audio
- Tone controls ( bass/treble ) for front L/R channels
VIDEO & AUDIO SUPPORT
- Supports features defined in HDMI 2.1 specification, including 8K/60p ( 4:4:4/12-bit*6 ), 8K/30p ( 4:4:4/12-bit*6, 4:2:2/12-bit*6, 4:2:0/12-bit ), 4K/120p ( 4:4:4/12-bit*6, 4:2:0/12bit ) video passthrough, VRR, ALLM, QFT ( Quick Frame Transport ), DSC ( Display Stream Compression ), QMS ( Quick Media Switching ) and eARC ( Main Out ); supports HDR10+, Dolby Vision™, HDR10, and HLG, and BT.2020 color; DeepColor™, x.v.Color™, LipSync, and HDCP 2.3
- Dolby Atmos, DTS:X, Dolby® TrueHD, and DTS-HD Master Audio® decoding
- Dolby Atmos Height Virtualizer and DTS Virtual:X 3D processing
- Dolby Surround® and DTS® Neural:X 3D upmixing solutions
- Hi-Res Audio playback via network and USB including DSD256, DSD128, DSD64 ( DSDIFF/DSF ) and 192 kHz/24-bit FLAC, ALAC, WAV ( RIFF ), and AIFF*7
- SACD ( Super Audio CD ) playback via HDMI (2.8 MHz 2-ch/ multichannel )
- Theater-Dimensional virtual surround-sound
- Sound optimization for games ( Rock, Sports, Action, and RPG )
- Direct Mode and Pure Audio Mode
NETWORK FEATURES
- SMART AV Receiver multi-room platform with integrated streaming services, voice assistant support, and control via remote apps
- Fast quad-core SoC supports 802.11ac ( 2x2 MIMO ) Wi-Fi
- Works with Sonos for the Sonos Home Sound System with Sonos app*8 control
- Works with Alexa supporting multi-room music*9
- Works with OK Google and Chromecast built-in
- Supports Apple AirPlay 2 enabling Siri voice control
- DTS Play-Fi supports Critical Listening mode via Onkyo Music Control App*8
- Control and manage media playback with the Onkyo Controller app*8
- Roon Tested certifi cation for the Roon Core
- IP Control for setup via PC and integration into a home automation system
CONNECTION FEATURES
- 4 HDMI inputs and 2 outputs ( Main Out [eARC], Sub Out )
- 2 digital audio inputs ( optical and coaxial, assignable )
- 3 analog RCA audio inputs ( assignable )
- 3.5 mm mic input for AccuEQ setup
- 6.35 mm headphone jack
- 2 subwoofer pre-outs
- Zone B analog RCA pre / line-level out
- Banana-plug-ready ( Front L/R / C/SL/SR/HL/HR ) speaker posts
- 10BASE-T/100BASE-TX Ethernet terminal for network connection
- USB input ( DC5 V / 1A ) for audio playback ( rear )
ADVANCED FEATURES
- AccuEQ Room Acoustic Calibration with AccuRefl ex phase correction and subwoofer EQ
- Bluetooth wireless technology supports wireless audio reception from mobile devices and PC, audio transmission to supported headphones (RX mode: SBC/AAC, TX mode: SBC/aptX/aptX HD)
- Advanced Music Optimizer™ improves compressed audio playback quality
- Wake on Play standby for Bluetooth and Network with auto inputswitching
- Vocal Enhancer boosts vocals/dialog audibility via remote control or front panel keys
- FM/DAB and AM tuner with 40 random station memory presets
- Height/Surround Back/Powered Zone B/Front Bi-Amp speaker terminals
- Zone B pre- / line-out shares MAIN audio source to a wireless headphone dock, hi-fi system, or active speaker system equipped with an analog RCA input
- My Input Volume one-touch startup volume assignment to individual inputs
- High-defi nition GUI with overlaid OSD over HDMI
- 1080p to 4K upscaling over HDMI
- OSD function shows source data and playback settings
- Independent crossover adjustment for each channel ( 40/50/60/70/8 0/90/100/120/150/180/200 Hz )
- A/V Sync Control ( up to 500 ms in 5 ms steps at 48 kHz*10 )
- Various standby modes and HDMI pass-through
- 3-Mode display dimmer ( Normal/Dim/Dimmer )
*1 Requires a Sonos Connect or Port (sold separately). Connection of 1 Sonos device is supported with volume control enabled via the Sonos app for iOS and Android™ devices. *2 Amazon Music HD is supported via DTS Play-Fi. *3 Streaming service availability may vary by region. An account and subscription may be required for some streaming services. *4 Voice control requires an Alexa built-in or Google Assistant-enabled device, such as a smart speaker or smartphone. Interoperability with streaming services depends on the respective technology and the country or region. *5 Some countries or regions have regulations that a ect wireless signal-strength and use of Wi-Fi channels. *6 DSC (Display Stream Compression) signals only. *7 Supported sampling-rates may vary depending on network environment. DSD is converted to PCM upon playback. ALAC is supported to a maximum 96 kHz. *8 Available free for iPhone and iPad at the App Store. Available free for Android devices on Google Play. Please check device and OS requirements before installation. *9 Multi-room music may require a rmware update. *10 Max. 400 ms (5 ms steps) at 96 kHz, and max. 200 ms (5 ms steps) at 192 kHz.
SPECIFICATIONS
Amplifier Section
Power output (All channels)
- 160 W/Ch (6 Ω, 1 kHz, 10% THD, 1-ch driven)
- 135 W/Ch (6 Ω, 1 kHz, 1% THD, 1-ch driven, IEC)
Dynamic power
- 160 W (3 ohms, Front)
- 125 W (4 ohms, Front)
- 85W (8 ohms, Front)
THD+N (Total Harmonic Distortion + Noise)
- 0.08% (20 Hz–20 kHz, half power)
Input sensitivity and impedance
- 32 k-ohms (Line)
Rated RCA output level and impedance
- 1 V rms/470 ohms (Subwoofer pre-out)
- 1V/200mV (Zone B Pre/Line-put)
Frequency response
- 10 Hz–100 kHz/+1 dB,
- -3 dB (Direct/Pure Audio)
Tone control
- ±10 dB, 20 Hz (Bass)
- ±10 dB, 20 kHz (Treble)
Signal-to-noise ratio
- 106 dB (Line, IHF-A)
Speaker impedance
- 4–16 ohms
Tuner Section
Tuning frequency range
- DAB (Europe): 174.928 MHz–239.2 MHz
- FM: 87.5 MHz–108MHz
- AM (Asia & Oceania)
- 522 kHz–1,611 kHz
- 530 kHz–1,710 kHz
DAB/FM/AM preset memory: 40 stations
General
Power supply: AC 220–240 V~, 50/60 Hz
Power consumption (operating): 480 W
Power consumption (idle): 48 W
Power consumption (standby): 0.15 W
Dimensions (W x H x D): 435 x 160 x 328 mm
Weight: 8.5 kg
Carton
Dimensions: (W x H x D): 525 x 240 x 405 mm
Weight: 10.5 kg
In the box
- Indoor FM/DAB antenna (Europe)
- I Indoor FM antenna (Asia & Oceania)
- AM loop antenna (Asia & Oceania)
- Speaker setup microphone
- Quick Start Guide
- Remote controller
- AAA (R03) batteries x 2
