Multichannel Surround
DTS HD Master / DTS:X / DTS:X Pro: Yes / Yes / Yes
DTS Neo:6 / DTS Neural:X: No / Yes
DTS Virtual:X: Yes
IMAX Enhanced: Yes
Dolby TrueHD / Dolby Atmos / Dolby Atmos Height Virtualization / Dolby Atmos Music: Yes / Yes / Yes / Yes
Dolby ProLogic Il / Dolby Surround: No / Yes
Auro 3D: Yes
360 Reality Audio / MPEG H: Yes / Yes
Audyssey DSX: No
Multichannel Stereo: Yes
Max. number of processing (preamp) channels: 13.4
Sound Enhancements
Mono Block Power Amp Construction: Yes
Discrete Power Amplifier: Yes
D.D.S.C. HD Digital: Yes (32 bit)
Pure Direct: Yes
Gold Plated RCA Terminals: Yes
Clock Jitter Reducer: Yes
Alpha Processing: AL32 Processing Multichannel
Audyssey: MultEQ XT32
Audyssey Dynamic EQ / Dynamic Volume: Yes / Yes
Audyssey LFC: Yes
Dirac Live upgradability: Yes
Compressed Audio Restorer: Yes
Network
Media Server: Yes
HEOS Wireless Multi-Room Technology: Yes
Bluetooth Re-transmit for Bluetooth headphones: Yes (With volume control)
Alexa / Google Voice Assistant / Apple HomePod: Yes / Yes / Yes
Lossy Formats: MP3 / WMA / AAC: Yes / Yes / Yes
Lossless Formats: FLAC / ALAC / WAV: Yes / Yes / Yes
Lossless Formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24: Yes / Yes / Yes
DSD Audio Streaming: Yes (2.8/5.6MHz)
FLAC HD 192/24: Yes
WAV 192/24: Yes
ALAC 192/24: Yes
Gapless playback: Yes (FLAC, WAV, ALAC ,DSD)
AirPlay Audio Streaming: Yes (AirPlay2)
Internet Radio: Yes (TuneIn)
Spotify Connect: Yes (connect)
Pandora: Yes
SiriusXM: Yes
Other Streaming Services: Amazon Music HD/ Amazon Music / TIDAL / Deezer / Soundcloud / Mood Mix
Roon Tested: Yes
HEOS App Control: Yes
Compatible with Remote APP for Smart Phones: Denon AVR Remote
Compatible with Remote APP for Tablets: Android / iOS / Amazon Kindle
Ethernet Ports: Yes
Wi-Fi: Yes
Bluetooth: Yes
HDMI
HDMI Inputs: Back, Front: 7 / No
HDCP2.3 support: Yes
HDMI Outputs: Main, Zone: 2 / 1
Video conversion Analog -> HDMI: Yes
HDMI to HDMI Scaling: 1080P/4K to 8K
HDMI 2.1: 8K/60 Hz AB / 4K/120 Hz AB: Yes / Yes
8K/60Hz AB / 4K/120Hz AB Pass-Through In/Out: 7 / 2 (up to 40Gbps)
HDMI 2.0: 3D / 4K / CEC / ARC / InstaPrevue: Yes / Yes / Yes / Yes / No
HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR: Yes / Yes / Yes / Yes / Yes
ALLM (Auto Low Latency Mode) Pass-Through for Gaming: Yes
Variable Refresh Rate / Quick Flame Transport / Quick Media Switching: Yes / Yes / No
3D Signal Pass-Through: Yes
8K Signal Pass-Through, Scaling, GUI Overlay: Yes / Yes / Yes
4K Signal Pass-Through / Scaling / GUI Overlay: Yes / Yes / Yes
HDMI Pass-Though in Standby Mode: Yes
CEC: Yes
DSD Audio capability: Yes
Audio Return Channel: ARC, eARC
Auto LipSync: Yes
Multi-room / CI
Multi-Room Zones: 3
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog: Yes (2ch) / Yes (2ch) / Yes / Yes
Zone Audio Output: Speaker / Pre-Out: Yes / Yes
Zone HDMI output from HDMI source: Yes
IP Control / RS232 Control / Web Control / App Control: Yes / Yes / Yes / Yes
Remote In / Out: Yes / Yes
DC Trigger output: 3
HDMI Diagnostics: Yes
Others
Auto speaker setup by microphone: Audyssey MultEQ XT32 Dirac Live (upgrade)
Front Display: 2 Line FLD
Graphic User Interface - GUI: Modern HD GUI
GUI Languages: 3
Setup Assistent: Yes
Quick Select Plus, Quick Select: Yes / No
Firmware Update by Network / USB: Yes / Yes
Variable cross over: Yes
Optimized Bass Redirection: Yes
Bass Sync: Yes
ECO Mode: Yes
Auto Power Off: Yes
Sleep Timer: Yes
Inputs Outputs
VIDEO
Composite In / Out: 2 / No
Component In / Out: 1 / No
HDMI In / Out: 7 / 3
Multi-Room Video Out: Video / HDMI: No / Yes
AUDIO
Analog In, Out: 6 / No
Phono (MM) In: Yes
Digital in: Optical/Coaxial: 2 / 2
Multi-Room Out: Analog/Digital: 2 / No
Multichannel Pre-out: Yes (13.4)
Subwoofer Out: 4 (independent)
OTHER
Speaker Terminal: Gold-Plated Screw / Regular Screw: Yes / No
Number of Speaker Terminals: 13
Speaker A / B: assignable
Bi-amp drive: assignable
Multi-Room Speaker Terminal: assignable
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB: No / No / No / No / Yes
USB Audio / Made for iPod / Made for iPhone: Yes / No / No
USB Power Supply on Rear Panel: Yes
AM/FM Tuner: No
Specifications
Number of Power Amps: 11
Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive): 140 W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive): 175 W
Power Output (6 ohm, 1 kHz, 1% 1ch Drive): 205 W
General
Metal Front Panel: Yes
System Remote Control: RC-1256
Pre-programmed / Learnable / LCD Display: Yes / No / No
Power Consumption in W: 750
Power Consumption No-Sound (ECO On / Off) in W: 65W / 110W
Standby Consumption in W: 0.1
CEC Standby Consumption in W: 0.5
Network Standby Consumption in W: Less than 2.0
Maximum Dimensions:
Antenna:Horizontal:(W x D x H) in mm: 434 × 389 × 167
( Antenna:Vertical :(W x D x H) in mm): (434 x 389 x 237)
【 w/o Antenna :(W x D x H) in mm】:(434 x 379 x 167)
Carton Dimensions (Packaging) (W x D x H) in mm): 531 x 465 x 303 (mm)
Weight in kg: 15.6
Weight in kg (Packaging): 18.2
Power Supply: AC 230 V, 50/60 Hz
Speaker Impedance: 4–16Ω/ohms
Input Sensitivity: 200 mV
Frequency Response: 10 Hz–100 kHz — +1, –3dB (Direct mode)
S/N Ratio: 102dB (IHF-A weighted, Direct mode)
