Preamplificator Phono USB NAD PP 4

NAD
Share

Ridicare gratuita din showroom

Cod produs: ref.28475

In stoc

899 lei / Bucata 1.399 lei

Expediere azi? Comanda in: Jul 28, 2026 16:00:00 +0300

30 de zile perioada de retur

Garantie 24 luni

Transport gratuit pentru comenzi peste 300 RON in Romania

Livrare prin curier sau ridicare din showroom Bucuresti

Pentru plata în rate alegeți NETOPIA ca procesator de plăți.

6 Rate

Card Avantaj

6 Rate

Alpha Bank

6 Rate

Banca Transilvania

6 Rate

Garanti Bank

12 Rate

Raiffeisen Bank (in showroom)

Descriere

Oferind calitati audio excelente, atat masurabil cat si audibil NAD ofera un produs versatil ce va permite sa treceti colectia dumneavoastra din format LP analog in format digital prin intermediul PP4.
Preamplificator de Doza cu inregistrare prin USB
Compatibil MM / MC
Impedanta selectabila pentru MC ( 100Ω + 180pF)
Gain @ 1kHz: 35 dB (MM) / 58 dB (MC)
Curbe de egalizare RIAA standard ±0.3dB
SNR > 78 dB (MC) / > 80dB (MM)

Alte informatii

Link producator: click aici

Fisa de produs: descarca fisierul

Specificatii tehnice Preamplificator Phono USB NAD PP 4

MC
Input Impedance (R and C): 100 Ohm + 180pF
Gain at 1kHz: 58dB
Input sensitivity (ref. 200mV output)0.38mV
Signal to noise (A weighted, with cartridge connected): 78dB
Input overload (20Hz/1kHz/20kHz): 0.65/6.5/60mV
Rated Distortion (THD 20Hz – 20kHz): <0.03%
RIAA response accuracy: ±0.3dB
Infrasonic filter: -14dB (5Hz)-3dB (10Hz)
Digital output (USB): 16 bit linear PCM
Sampling frequency: 48kHz
Dynamic range: 86dB

MM
Input Impedance (R and C): 47 kilohm + 200pF
Gain at 1kHz: 35dB
Input sensitivity (ref. 200mV output): 5mV
Signal to noise (A weighted, with cartridge connected): 76dB
Input overload (20Hz/1kHz/20kHz): 10/100/900mV
Rated Distortion (THD 20Hz – 20kHz): <0.03%
RIAA response accuracy: ±0.3dB
Infrasonic filter: -14dB (5Hz)-3dB (10Hz)
Digital output (USB): 16 bit linear PCM
Sampling Frequency: 48kHz
Dynamic range: 89dB
Record Level: 0dB to -6dB
Gross Dimensions excl. Power supply (W x H x D)*: 135 x 49 x 72mm 5 5/16 x 1 15/16 x 2 7/8″**
*Gross dimensions include feet, extended buttons and rear panel terminals.
**Non-metric measurements are approximate.

Line In
Input Impedance: 47 kilohm + 180pF
Rated Distortion (THD 20Hz – 20kHz): <0.008%
Signal to noise, A weighted: -115dB
Maximum Input Level: 5.3V

Line Out
Output Impedance: 100 Ohm
Maximum Output Level: 5.3V
