Design: Three-way bass reflex
Sensitivity (2.83V/1m): 90dB
Frequency range (-6dB): 30Hz - 50kHz
Typical in-room bass response (-6dB): 26Hz
Frequency Response (±3dB): 30Hz - 50kHz
Amplifier power (recommended): 15-300W
Harmonic distortion (90dB, 1m): <0.3% 120Hz - 20kHz
Crossover frequency: 400Hz, 2.9kHz
Drive units:
Uni-Q Driver Array:
HF: 25mm (1in.) vented aluminium dome
MF: 125mm (5in.) aluminium cone
Bass Driver:
LF: 4 x 165mm (6.5in.) hybrid aluminium
Maximum Output: 113dB
Nominal impedance: 8Ω (min.3.7Ω)
Dimensions (H x W x D): 1249 x 200 x 383.5 mm (49.2 x 7.9 x 15.1 in.)
Dimensions (H x W x D) with terminal with Plinth: 1295.5 x 310.6 x 383.5 mm (51 x 12.2 x 15.1 in.)
Net Weight: 37.7 kg (83.1 lbs.)
