Caracteristici principale
- Boxa de podea
- Difuzoare: 1 x tweeter 2.5cm + 1 x medii 12.5cm + 6 x woofer 25cm + 1 x mid-bass 25cm
- Raspuns in frecventa : 25 Hz – 60 kHz
- Sensibilitate : 90 dB ( 2.83V @ 1 m )
- Impedanta nominala: 4 ohm
- Amplificare recomandata: 100 - 400 W
Link producător:
Greutate produs
Dimensiuni produs
Alte specificații
Design pe 4 cai, incinta sigilata
Crossover frequencies: 120Hz, 300Hz, 2.3kHz
Maximum output: 118dB
Garanție (luni)
A triumph of form marrying function, MUON is perhaps the most extraordinary loudspeaker ever conceived
A KEF Concept designed by Ross Lovegrove
The MUON project is ambitious to say the least. Visionary deisgner Ross Lovegrove was tasked with turning the finest acoustic engineering into the ultimate loudspeaker by combining form and function with manufacturing integrity. The MUON loudspeaker is fabricated from super-formed aluminium to create a shape that is devoid of sharp edges and extremely stiff. It combines Ross Lovegrove's design aesthetics with KEF's finest engineering. The process by which MUON was conceived meant that, in effect, Ross Lovegrove was sculpting the sound by 'skinning' the technology with purposeful form - the final shape was created through an evolutionary process that makes it perfectly suited to its purpose.
The MUON Story
MUON is a truly remarkable feat of sound-engineering and cutting-edge design. Rarely does one find such a sublime marriage of form, function and manufacturing integrity in any field. Individually crafted and carefully measured in KEF's highly accurate anechoic chambers, each loudspeaker comes with a certificate showing its unique frequency response curve, signed by the skilled craftsman who made it in KEF's Maidstone workshop.
The Technology Behind MUON
MUON's powerful bass drivers are one element that makes it so superior. But it is also the upper mid-range and treble where some of the key technology lies, the Uni-Q® drive unit array which delivers seamless imaging throughout the room. KEF also used Acoustic Compliance Enhancement (ACE) technology, this effectively doubles the available volume through adsorption of air molecules by activated carbon.
Perfect musical form
Ross Lovegrove's design for the MUON is more than just a beautiful form in polished aluminium. It provides the drivers with the perfect environment to deliver seamless, open sound. The curvaceous torso like form breaks up the visual mass of the cabinet whilst providing a smooth, unbroken surface that allows sound radiate out and create a field of pure sound. The result is music with unprecedented three-dimensional presence.
Technical Specifications
Design: Four-way closed box floorstanding loudspeaker ACE enclosure
Dimensions(H x W x D): 2000 x 600 x 380 mm (78.8 x 23.6 x 15 in.)
Weight: 115kg (253lbs)
Drive Units:
1 x 250mm (10in.) LMF,
Uni-Q driver array:
MF: 1 x 125mm (5in.) Li-Mg-Al /LCP, hybrid cone
HF: 1 x 25mm (1in.) vented aluminium dome, featuring KEF's unique 'Tangerine Waveguide'
Frequency Response: 25Hz to 60kHz * (±3dB)
Crossover Frequencies: 120Hz, 300Hz, 2.3kHz
Amplifier Requirements: 100 to 400W (typical)
Sensitivity: 90dB (2.83V/1m)
Input Impedance: 4 Ohms
Low Frequency Extension: 20Hz (-6dB) *
High Frequency Extension: 100kHz (-10dB) *
Maximum Output: 118dB
