Nominal impedance: 8Ω
Sensitivity (2.83V/1m): 90dB
Frequency response (±6dB) open-backed: 35Hz - 34kHz
Nominal coverage: 115°
Max SPL: 107dB
Crossover frequency: 2.5kHz
Drive units:
LF 200mm (8in.) Uni-Q
MF -
HF 25mm (1in.)
Recommended amplifer power: 10-150W
Recommended high-pass flter: 40Hz
Product external dimensions (H x W x D): 369 x 273 x 105.9mm (14.53 x 10.75 x 4.17in.)
Cut-out dimensions (H x W): 330 x 234mm (12.99 x 9.21in.)
Mounting depth from surface: 99.8mm (3.93in.)
Net Weight: 2.6kg (5.77lbs.)
Ideal rear volume: 60L
Minimum rear volume: 35L
