Nominal impedance: 4Ω
Sensitivity (2.83V/1m): 90dB
Frequency response (±6dB) open-backed: 52Hz - 24kHz
Nominal coverage: 130°
Max SPL: 105dB
Crossover frequency: 2.1kHz
Drive units:
LF 165mm (6.5in.) Uni-Q
MF -
HF 25mm (1in.)
Recommended amplifer power: 10-190W
Recommended high-pass flter: 38Hz
Product external dimensions: Diameter Ø 234.6mm (9.24in.); Depth 115mm (4.53in.)
Cut-out dimensions: Diameter Ø 196mm (7.71in.)
Mounting depth from surface: 110mm (4.33in.)
Net Weight: 2.94kg (6.48lbs.)
Ideal rear volume: 20L
Minimum rear volume: 10L
THX certification THX®: Certified Ultra
Safety and Regulatory Compliance: IP64
