Nominal impedance: 8Ω
Sensitivity (2.83V/1m): 89dB
Frequency response (±6dB) open-backed: 52Hz - 20kHz
Nominal coverage: 120°
Max SPL: 104dB
Crossover frequency: 2.5kHz
Drive units:
LF 160mm (6.5in.) Uni-Q
MF -
HF 16mm (0.6in.)
Recommended amplifer power: 10-100W
Recommended high-pass flter: 50Hz
Product external dimensions (H x W x D): 303 x 223 x 91 mm (11.93 x 8.78 x 3.58in.)
Cut-out dimensions (H x W): 270 x 190 mm (10.63 x 7.48in.)
Mounting depth from surface: 84.5mm (3.33in.)
Net Weight: 1.6kg (3.5lbs.)
Ideal rear volume: 35L
Minimum rear volume: 20L
