Nominal impedance: 8Ω
Sensitivity (2.83V/1m): 87dB
Frequency response (±6dB) open-backed: 45Hz - 34kHz
Nominal coverage: 130°
Max SPL: 103dB
Crossover frequency: 3.8kHz
Drive units:
LF 130mm (5.25in.) Uni-Q
MF -
HF 19mm (0.75in.)
Recommended amplifer power: 10-100W
Recommended high-pass flter: 50Hz
Product external dimensions (H x W x D): 184 x 184 x 83 mm (7.24 x 7.24 x 3.27in.)
Cut-out dimensions (H x W): 154 x 154mm (6.10 x 6.10in.)
Mounting depth from surface: 77.1mm (3.03in.)
Net Weight: 1.4kg (2.7lbs.)
Optional rough in frame: RIF130S
Optional rear enclosure: RNC130S
Ideal rear volume: 15L
Minimum rear volume: 10L
