Nominal impedance: 8 Ohms
Sensitivity (2.83V/1m): 87dB
Frequency response (±6dB) open-backed: 45Hz - 34kHz
Nominal coverage: 130°
Max SPL: 103dB
Crossover frequency: 3.8kHz
Drive units:
LF 130mm (5.25in.) Uni-Q
MF -
HF 19mm (0.75in.)
Recommended amplifier power: 10 - 100 W
Recommended high-pass filter: 50Hz
Product external dimensions: Diameter Ø 193.4mm (7.61in.); Depth 83.0mm (3.27in.)
Cut-out dimensions: Diameter Ø 154.0mm (6.10in.)
Mounting depth from surface: 77.8mm (3.06in.)
Net Weight: 1.35kg (2.97lbs)
Optional rough in frame: RIF130R
Optional rear enclosure: RNC130R
Ideal rear volume: 15L
Minimum rear volume: 10L
