Nominal impedance: 8Ω
Sensitivity (2.83V/1m): 87dB
Frequency response (±6dB) open-backed: 52Hz - 20kHz
Nominal coverage: 140°
Max SPL: 102dB
Crossover frequency: 2.8kHz
Drive units:
LF 130mm (5.25in.) Uni-Q
MF -
HF 16mm (0.6in.)
Recommended amplifer power: 10-80W
Recommended high-pass flter: 55Hz
Product external dimensions (H x W x D): 184 x 184 mm x 83 mm (7.24 x 7.24 x 3.27in.)
Cut-out dimensions (H x W): 154 x 154mm (6.10 x 6.10in.)
Mounting depth from surface: 77.1mm (3.03in.)
Net Weight: 1.2kg (2.7lbs.)
Optional rough in frame: RIF130S
Optional rear enclosure: RNC130S
Ideal rear volume: 20L
Minimum rear volume: 12L
