Series: Classic Series
Nominal impedance: 8 Ohms
Sensitivity (2.83V/1m): 89dB
Frequency response (±6dB) with back can / rear enclosure: 110Hz - 18kHz
Frequency range (-10dB): 105Hz - 30kHz
Nominal coverage (degrees): 170°
Max SPL (dB): 98dB
Crossover frequency -
Net weight: 2.25kg (4.95lbs)
Mounting depth from surface with back can: 107mm (4.21in.)
Optional rough in frame: RIF160R
Ideal rear volume (L): 5L
Minimum rear volume (L): 1L
Certification: UL2043; UL1480-5
Drive units:
LF 110mm (4.3in.)
HF -
Recommended amplifier power: 10 - 100W
Recommended high-pass filter (Hz): 110Hz
Transformer taps: 70V: 4W, 8W, 15W, 30W; 100V: 8W, 15W, 30W
Product external dimensions:
Diameter Ø 220mm (8.66in.)
Depth 110mm (4.33in.)
Cut-out dimensions: Diameter Ø 196mm (7.71in.
