Frequency Response
On Axis @ 0° ±3dB: 55 - 21,000Hz
On Axis @ 0° ±1 1/2dB: 65 - 20,000Hz
Off Axis @ 30° ±1 1/2dB: 65 - 10,000Hz
LF Cutoff -10dB: 37Hz
Sensitivity
Anechoic Chamber: 87dB
Listening Room: 89dB
Impedance
Nominal: 8 Ohms
Minimum: 4 Ohms
Input Power
Recommended: 10 - 90 Watts
Program: 60 Watts
Acoustic Design
Tweeter (Nominal): 3/4” (19mm)Black Anodized Aluminium Dome with Ferrofluid and Neodymium Magnet
Woofer (Nominal): 5 1/4” (133mm) Textured Polypropylene Cone with Rubber Surround
Crossover: 2,500Hz, L4
Internal Volume: 0.29 cu ft (8.3L)
Design Type: Tuned Port Bass Reflex, 2” (49mm) Rear Port
Dimensions / Weights
Size (W x H x D): 6 3/4” x 11 3/8” x 9 1/2”* (170 x 290 x 240mm)
Weight: 10.15lb (4.6kg)/each22.8lb (10.4kg)/pr
