Frequency Response
On Axis @ 0° ±3dB: 57 - 21,000Hz
On Axis @ 0° ±1 1/2dB: 67 - 20,000Hz
Off Axis @ 30° ±1 1/2dB: 67 - 10,000Hz
LF Cutoff -10dB: 43Hz
Sensitivity
Anechoic Chamber: 85dB
Listening Room: 87dB
Impedance
Nominal: 8 Ohms
Minimum: 4 Ohms
Input Power
Recommended: 10 - 80 Watts
Program: 60 Watts
Acoustic Design
Tweeter (Nominal):
3/4” (19mm)
Black Anodized Aluminium Dome with Ferrofluid and Neodymium Magnet
Woofer (Nominal):
4” (102mm)
Textured Polypropylene Cone with Rubber Surround
Crossover: 3,000Hz, L4
Internal Volume: 0.11 cu ft (3.1L)
Design Type:
Tuned Port Bass Reflex, 1 3/8” (35mm) Rear Port
Dimensions / Weights
Size (W x H x D): 5 1/8” x 8 5/8” x 6 7/8”* (130 x 220 x 174mm)
Weight: 4.9lb (2.2kg)/each 11.45lb (5.2kg)/pr
