Frequency response (–6 dB): 56 Hz - 25 kHz
Max. short term sine wave acoustic output on axis in half space, averaged 100 Hz - 3 kHz at 1 m: > 100 dB SPL
Maximum long term RMS acoustic output in same conditions with IEC weighted noise (limited by driver unit protection circuit) at 1 m: > 93 dB SPL
Self generated noise level in free field at 1 m on axis (A-weighted): < 5 dB
Harmonic distortion at 85 dB SPL at 1 m on axis: 50...200 Hz < 3 %
>200 Hz < 0.5 %
Input connector type: 1 RCA female
Input impedance: 10 kOhm:
Crossover frequency, Bass/Treble: 3.0 kHz
Tabletop control operating range: -4 dB at 200 Hz
Bass control operating range in –2 dB steps: 0 to -6 dB at 100 Hz
Low Bass control operating range: -4 dB step at 65 Hz
Bass amplifier power (long term output power is limited by driver unit protection circuitry): 50 W
Treble amplifier power (long term output power is limited by driver unit protection circuitry): 50 W
Amplifier system distortion at nominal output THD+N: < 0.05 %
Mains voltage: 100-240 V AC, 50-60 Hz
Voltage operating range: ±10 %
Power consumption
Standby (ISS active): <0.5 W
Idle: 3 W
Full output: 60 W
Bass driver: 105 mm (4 in)
Treble driver: 19 mm (3/4 in)
Weight: 3.2 kg (7 lbs)
Dimensions:
Height including Iso-Pod™ table stand: 242 mm (91/2 in)
Height without Iso-Pod™ table stand: 230 mm (91/16 in)
Width: 151 mm (6 in)
Depth: 142 mm (55/8 in)
