SYSTEM SPECIFICATIONS
Lower cut-off frequency, -6 dB: ≤ 47 Hz
Upper cut-off frequency, -6 dB: ≥ 25 kHz
Maximum short term sine wave acoustic output on axis in half space, averaged from 100 Hz to 3 kHz:
@ 1 m: ≥ 104 dB SPL
@ 0.5 m: ≥ 110 dB SPL
Maximum long term RMS acoustic output in same conditions with simulated programme signal according to IEC 60268-1 (limited by driver unit
protection circuit) @ 1 m: ≥ 96 dB SPL
Self generated noise level in free field @ 1m on axis (A-weighted): ≤ 5 dB
Harmonic distortion @ 1 m on axis: @ 85 dB SPL
Freq. 50 to 100 Hz: < 2 %
> 100 Hz: < 0.5 %
Drivers:
Bass: 130 mm (5 in)
Treble: 19 mm (3/4 in) metal dome
Weight: 5.0 kg (11 lbs)
Dimensions:
Height (without table support): 285 mm (11 1/4 in)
Height (including table support): 299 mm (11 13/16 in)
Width: 189 mm (7 7/16 in)
Depth: 178 mm (7 in)
CROSSOVER SECTION
Input connectors:
XLR female: 1
RCA female: 1
Input impedance: 10 kOhm
Crossover frequency, Bass/Treble: 3.0 kHz
Treble control operating range in 2 dB steps: -2 dB @ 15 kHz
Tabletop low frequency control operating range: -4 dB @ 200 Hz
Low Bass control operating range: -4 dB @ 55 Hz
Bass control operating range in 2 dB steps: From 0 to -6 dB @ 100 Hz
AMPLIFIER SECTION
Bass amplifier short term output power: 50 W
Treble amplifier short term output power: 50 W
Long term output power is limited by driver unit protection circuitry
Amplifier system distortion at nominal output:
THD: ≤ 0.05 %
SMPTE-IM: ≤ 0.05 %
CCIF-IM: ≤ 0.05 %
DIM 100: ≤ 0.05 %
Signal to Noise ratio, referred to full output:
Bass: ≥ 100 dB
Treble: ≥ 100 dB
Mains voltage: 100 - 240 V AC, 50-60 Hz
Voltage operating range: ±10 %
Power consumption:
Standby: <0.5 W
Idle: 3 W
Full output: 60 W
