Frequency Response:
On Axis @ 0° ±3dB: 48Hz - 20,000Hz
Sensitivity:
Anechoic Chamber: 85dB
Listening Room: 87dB
Impedance:
Nominal Impedance: 6 Ohms
Minimum Impedance: 4 Ohms
Input Power:
Recommended Power Range: 10 - 100 Watts
Acoustic Design:
Tweeter: 1” (25mm) Treated Textile Dome with Ferrofluid
Woofer: 8” (203mm) Stamped Steel Basket, Black Polypropylene Cone Foam Surround
Crossover: 1st Order High Pass
Design Type: Open Back
Dimensions / Weights
Size (W x H x D):
Cutout Diameter: 9 3/4” (245mm)
Mounting Depth: 4 3/8" (111mm)
Round Grille Diameter: 10 5/8" (270mm)
Weight:
Net Weight per Speaker: 3.25 lbs (1.47 kg)
