PRODUCT HIGHLIGHTS
220 W/Ch THX® Certified Select Dynamic Audio Amplification system
IMAX® Enhanced certified for immersive signature sound by DTS:X®
5.2.4-ch/7.2.2-ch Dolby Atmos® and DTS:X playback
Supports Dirac Live® Room Correction: 20Hz to 20kHz
AccuReflex phase-matching solution for Atmos-enabled speakers
SMART AV Receiver™: Works with Sonos, Chromecast built-in™, AirPlay 2, and DTS Play-Fi®; includes Spotify®, Amazon Music HD, Pandora®, TIDAL, Deezer, and TuneIn streaming services
Works with Hey Google or Alexa: Sold separately
Stream over 5 GHz/2.4 GHz dual-band Wi-Fi® supporting the 802.11ac standard
HDMI® inputs: Inputs 1-3 and Main/Sub out support 8K/60AB and 4K/120AB. Inputs 4-6 support 8K/60B and 4K/120AB. Front HDMI Input supports up to 4K/60 (HDMI 2.0).
HDMI 2.1: HDMI 2.1 features that are supported on HDMI inputs 1–6, Main Out, and Sub/Zone 2 Out in Sub Mode output including VRR, ALLM, QFT (Quick Frame Transport), DSC (Display Stream Compression), QMS (Quick Media Switching), and eARC (Main Out).
HDMI Sub/Zone 2 Out for media transmission to a second display
Send or receive audio via Bluetooth® wireless technology: RX mode: SBC/AAC, TX mode: SBC/Qualcomm® aptX™/ aptX HD
Refined chassis, HDMI board, DAC, Digital/Analog inputs, power-amp grounds and power lines
5.2-ch Main + Powered Zone 2 + Powered Zone 3 speakers support synced/independent D/A audio playback
Zone 2/Zone B line-out*7 (analog RCA) supports synced or independent D/A playback*8 on compatible audio systems or headphone docks
AMPLIFIER
Power output (All channels): 220 W/Ch (6 ohms, 1 kHz, 10% THD,1-ch driven) 100 W/Ch (8 ohms, 20 Hz–20 kHz, 0.08% THD, 2-ch driven, FTC)
Dynamic power: 250 W (3 ohms, Front) 220 W (4 ohms, Front) 130 W (8 ohms, Front)
THD+N (Total Harmonic Distortion + Noise): 0.08% (20 Hz–20 kHz, half power)
Input sensitivity and impedance: 200 mV rms/47 k-ohms (Line) 3.5 mV rms/47 k-ohms (Phono MM)
Rated RCA output level and impedance: 1 V rms/470 ohms (Subwoofer pre-out) 200 mV rms/470 ohms (Zone 2/Zone B line-out)
Frequency response: 10 Hz–100 kHz/+1 dB, -3 dB (Direct/Pure Audio)
Tone control: ±10 dB, 20 Hz (Bass) ±10 dB, 20 kHz (Treble)
Signal-to-noise ratio: 106 dB (Line, IHF-A) 80 dB (Phono, IHF-A)
Speaker impedance: 4–16 ohms
TUNER
FM: 87.5 MHz–107.9 MHz
AM: 530 kHz–1,710 kHz
FM/AM preset memory: 40 stations
GENERAL
Power supply: AC 120 V~, 60 Hz
Power consumption (operating): 750 W
Power consumption (idle): 75 W
Power consumption (standby): 0.1 W
Dimensions (W x H x D): 17 1/8˝ x 6 13/16˝ x 14 15/16˝ (435 x 173.5 x 379.5 mm)
Weight: 22.9 lbs. (10.4 kg)
IN THE BOX
Power cord
Indoor FM antenna
AM loop antenna
Speaker setup microphone
Quick Start Guide
Remote control
Two AAA (R03) batteries
