GENERAL SPECIFICATIONS
All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter.
LINE INPUT, SPEAKER OUT
Continuous Output Power into 8 Ohms:
>120 W (all channels driven)
>130 W (two channels driven)
Continuous output power into 4 ohms:
>135 W (all channels driven)
>230 W (two channels driven)
Continuous output power into 8 ohms at Bridged mode:
>200 W (all channels driven)
>320 W (two channels driven)
THD (20 Hz – 20 kHz): <0.05 % (1 W to 100 W, 8 ohms and 4 ohms)
Signal-to-Noise Ratio: >88 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)
Clipping power (all channels driven):
>130 W (1 kHz 8 ohms 0.1 % THD)
>150 W (1 kHz 4 ohms 0.1 % THD)
Clipping power into 8 ohms at Bridged mode:
>300 W (1 kHz 0.1 % THD – all channels driven)
>400 W (1 kHz 0.1 % THD – two channels driven)
IHF dynamic power (all channels driven):
8 ohms: 125 W
4 ohms: 200 W
2 ohms: 180 W
IHF dynamic power (two channels driven):
8 ohms: 145 W
4 ohms: 260 W
2 ohms: 300 W
IHF dynamic power (Bridged mode, all channels driven):
8 ohms: 440 W
4 ohms: 350 W
2 ohms: 230 W
IHF dynamic power (Bridged mode, two channels driven):
8 ohms: 480 W
4 ohms: 380 W
2 ohms: 300 W
Peak output current: >20 A (1 ohm, 1 ms)
Damping Factor: >110 (ref. 8 ohms, 20 Hz to 6.5 kHz)
Frequency Response: ±0.5 dB (20 Hz – 20 kHz)
Channel separation: >70 dB (1 kHz)>65 dB (10 kHz)
Maximum undistorted input level: 2900 mV
Input sensitivity (for 120 W in 8 ohms, maximum volume): 1150 mV
Analog Input audio sense threshold (one channel with signal): 3 ± 0.5 mVrms (ref. 100 Hz – 10 kHz)
Trigger IN leve: l3 – 30 Vdc
Standby power: 0.5W
DIMENSION AND WEIGHT
Dimensions (W x H x D): 483 x 45 x 435 mm (19 1/16 x 1 13/16 x 17 3/16”)
Shipping Weight: 10 kg (22 lbs)
