GENERAL
Continuous output power into:
8 ohms:
60 W (all channels driven, 1kHz 0.05% THD
65 W (two channels driven, 1kHz 0.05% THD
4 ohms:
65 W (all channels driven, 1kHz 0.05% THD
105 W (two channels driven, 1kHz 0.05% THD
Continuous output power into 8 ohms at Bridged mode:
140 W (all channels driven, 1kHz 0.05% THD
240 W (two channels driven, 1kHz 0.05% THD
THD (1 W to 50 W, 8 ohms and 4 ohms):
0.05 % (20 Hz – 3 kHz)
0.2 % (3kHz – 20 kHz)
Signal-to-Noise Ratio: 80 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)
Clipping power (all channels driven):
60 W (1 kHz 8 ohms 1 % THD)
80 W (1 kHz 4 ohms 1 % THD)
Clipping power into 8 ohms at Bridged mode:
150 W (1 kHz 1 % THD – all channels driven)
250 W (1 kHz 1 % THD – two channels driven)
IHF Dynamic Power (all channels driven):
8 ohms: 65 W
4 ohms: 125 W
IHF Dynamic Power (two channels driven):
8 ohms: 70 W
4 ohms: 125 W
IHF dynamic power (Bridged mode, all channels driven): 8 ohms: 270 W
IHF Dynamic Power (two channels driven): 8 ohms: 280 W
Peak output current: 15 A (1 ohm, 1 ms)
Damping factor: 110 (20 Hz to 1 kHz 8 ohms)
Frequency response: ±1dB (20 Hz – 20 kHz)
Channel separation:
60 dB (1 kHz)
55 dB (10 kHz)
Maximum undistorted input level: 2900 mV
Input sensitivity (for 50 W in 8 ohms, maximum volume): 760 mV
Input impedance: 20 kohms//220pF
Analog input audio sense threshold (one channel with signal): 3 ± 0.5 mVrms (ref. 100 Hz – 10 kHz)
Trigger IN level: 3 – 30 Vdc
Standby power: 0.5W
DIMENSION AND WEIGHT
Gross dimensions (W x H x D): 483 x 100 x 435 mm (19 1/16 x 3 15/16 x 17 3/16 inches)
Net Weight: 10.3 kg (22.7 lbs)
Shipping Weight: 12.8 kg (28.2 lbs)
