| Inputs | |
| Wireless | ESS Sabre 44.1/48k 16-Bit (AAC, aptX, aptX LL and SBC) |
| Wired | 3.5mm (TRS or TRRS S-Balanced*) and 2.5mm (TRRS) *ONLY found in iFi components such as nDSD BL. Do NOT feed using normal TRRS Balanced output sources. No USB audio input |
| Max Output | |
| S-Balanced | > 3.8V / 45 mW (@ 300 Ohm)> 3.5V / 380 mW (@ 32 Ohm)> 3.1V / 600 mW (@ 16 Ohm |
| Balanced | > 7.6V / 90 mW (@ 600 Ohm)> 7.2V / 800 mW (@ 64 Ohm)> 5.7V / 1,000 mW (@ 32 Ohm) |
| THD & N | |
| S-Balanced | < 0.005% (@ 100 mW/1.26V 16 Ohm) |
| Balanced | < 0.006% (@ 360 mW/2.4V 16 Ohm) |
| SNR | |
| S-Balanced | > 121dBA (@ 3.8V) |
| Balanced | >120dBA (@ 7.6V) |
| Recommended HP Impedance | 16~600 Ohm |
| Output impedance | |
| S-Balanced | <1 Ohm |
| Balanced | <2 Ohm |
| Max. Input | |
| S-Balanced | 3V RMS |
| Balanced | 6V RMS |
| Gain | -95dB to +18dB adjustable in 114 1dB steps (using volume control) |
| Frequency Response | < 2Hz – > 200kHz (-3dB) |
| Playback Time | 18 hours (analogue) or 12 hours (Bluetooth) (charging via USB port) |
| Dimensions | 95 (l) x67 (w) x19 (h) mm |
| Weight | 127g (0.28 Ibs) |
