Audio
Supported Audio File Formats: MP3, AAC, WMA, WMA-L, OGG, ALAC, OPUS
Audio Controls & EQ: BluOS Control App
Amplification: DirectDigital™
Supported Hi-Res Audio File Formats: FLAC, MQA, WAV, AIFF, MPEG-4 SLS
Bit Depth: 16-24
Rated Power Output: 100W x 2 | 80W x 3 (8 Ohms)
Supported Multi-Channel Audio Formats: Dolby® Digital
Signal-to-Noise Ratio: 102dBA
IHF Dynamic Power: 265W (4 Ohms) | 140W (8 Ohms)
Native Sampling Rates: up to 192 kHz
DSD Support: DSD256
Distortion: THD+N, 0.005%
Software & Integrations
Operating System: BluOS
Music Services & Internet Radio: 23+
3rd-Party Integrations: AirPlay 2, Spotify Connect (also support for Spotify Lossless), Tidal Connect, Roon Ready, Dirac Live Ready (available via future software update)
App Controller Operating System: iOS, Android, Windows, macOS
Album Art Supported: JPG, PNG
Control System Integrations: Creston, Control4, RTI, Nice, URC, Lutron
Supported Network File Sharing: Server Messsage Block (SMB) up to 200,000 files
Processor: ARM® Cortex™ -A53, Quad-Core, 1.8GHz per core
Voice Control Integrations: Amazon Alexa Skills
General
Generation: 3
Storage Environment: -10°C to 50°C, 20% to 80% relative humidity
Product Dimensions:
220 x 70 x 190 mm (8.7 x 2.75 x 7.5 in)
1.9 kg / 4.18 lbs
Shipping Dimensions:
295 x 295 x 110 mm (11.6 x 11.6 x 4.33 in)
3.43 kg / 7.56 lbs
Operating Environment: 0°C to 40°C
User Interface & Control
Status Indicator: LED x 2
Volume Control Buttons: Touch Slider LED
Preset Buttons: Touch LED x 5
Play/Pause Button: Touch LED
Previous/Next Track Buttons: Touch LED
Proximity Sensor: Yes
Connections
Ethernet/LAN: Ethernet RJ45, Gigabit 1000Mbps
Bluetooth Connectivity: Two-Way (transmit & receive)
Bluetooth Quality: Bluetooth 5.2 aptX HD
IR Optical Built In: IR Sensor Built in - front panel with IR learning
Headphone Output: 6.35mm Stereo; Bluetooth
USB IN: Type A (Fat32, NTFS Formatted) - External Storage Only
Local Server Mode
Optical/Analog Input: Toslink Optical, RCA Analog, 3.5mm Optical/Analog Combo
Subwoofer Output: RCA x 1; Wireless to PULSE SUB+
IR Input: 3.5mm Jack
HDMI Input: HDMI eARC
Wi-Fi Built In: WiFi 5 (802.11ac), dual-band
USB Audio: USB Type C (PC input)
Speaker Terminals: 5-Way Binding Post
